See the air
employees breathe

Wondering why your employees seem lethargic? Noticing more people going on sick leaves?

No need to guess when you can see exactly what’s going on via uHoo’s 13 environment sensors* and virus index.

Temperature
Relative Humidity
Carbon Dioxide
Carbon Monoxide
Dust PM1
Dust PM2.5
Dust PM4
Dust PM10
Formaldehyde
Air Pressure
Light
VOCs
Sound
Sulfur Dioxide
Hydrogen Dioxide
Nitrogen Dioxide
Ammonia
Ozone
Virus Index
Mold Index
Book a meeting

Technical Specifications

Download

INSTALLATION

Wall-mounted/Table-top

OPERATING TEMPERATURE

0°C to 40°C (32°F to 104°F) in normal / non-battery-charging mode
10°C to 40°C (50°F to 104°F) in battery-charging mode

OPERATING HUMIDITY

0% to 95% non-condensing

BUILT-IN FAN

Yes

OTA FRIMWARE UPDATE

Yes

ACCESSORIES

5V/2A USB Adapter (Region-specific), 2m USB Data Cable, Mounting Tape, Tapping Screws, Wall Plugs, Air Health and Virus Index Sticker

Choose your connectivity protocol from the following options *

1. Cellular

STANDARD

LTE-M or NB-IoT

FREQUENCY BANDS

1/2/3/4/5/8/12/13/18/19/20/26/28 (Multi-regional. 1 and 26 are Roaming Bands)

SIM CARD

Micro-SIM supporting LTE-M or NB-IoT connectivity. Contact your Local Telecommunication Service Provider for Network Coverage.



2. Wi-Fi (Setup using mobile)

STANDARD

802.11 a/b/g/n @ 2.4GHz and 5GHz (20MHz channels only)

SECURITY

Open, WEP, WPA/WPA2-Personal

IP ADDRESSING

IPv4 + DHCP

* There is only one connectivity protocol used by each device. Be sure to select your preferred option when ordering to ensure it is compatible with your setup.

MAIN POWER SOURCE

5V/2A USB Adapter, or via PoE to USB converter

BACK UP POWER SOURCE

3250mAh @ 3.6V lithium-ion battery

POWER CONSUMPTION

900mW (normal operation) and 1.1W (data transmission)

FREQUENCY

Once per minute

BACKUP

Up to 15 minutes during network outage. Permanent on Cloud.

FORMAT

Minute-by-minute or Hourly-average

APIs

Yes. Polling only.

uHoo ACCOUNT

Contact business@getuhoo.com for account registration

WEB DASHBOARD

https://web.getuhoo.com (support all major browsers)

MOBILE APP

uHoo Business

MINIMUM OS REQUIREMENTS

iOS 11 (64-bit Devices) or Android 5.0 and Versions Above

DIMENSIONS (W x L x D)

200mm x 180mm x 57mm or 7.8in x 7.1in x 2.2in

WEIGHT

765g or 1.7lbs

MATERIAL

ABS plastic

MECHANICAL PROTECTION

Dust-filtering mesh

LIGHT INDICATORS

SIM, Wi-Fi, Battery

MAIN POWER SOURCE

5V/2A USB Adapter, or via PoE to USB converter.

BACKUP POWER SOURCE

3250mAh @ 3.6V Lithium-ion Battery

POWER CONSUMPTION

900 mW (Normal Operation) and 1.1 W (Data Transmission)

SCREEN DISPLAY

No

RADIO

FCC, IC, CE, TELEC, NTC

SAFETY

FCC, IC, CE, PSE

BATTERY

UN38.3, UL 62368, CB (IEC 62133-2017), PSE

ENVIRONMENTAL

RoHS, REACH, WEEE, Free of SCCP and HBCDD Contents, Green Building Product (SGBC)

PERFORMANCE

MCERTS, RESET Air Accredited Grade B monitor, RESET Accredited Data Provider


Unit
Range
Resolution
Accuracy
Temperature
°C
-40 to 85°C
0.1°C
±0.5°C
Relative Humidity
%
0 to 100%
0.1%
±3%
Air Pressure
hPa
300 to 1,100hPa
0.1 hPa
±1hPa
Light
lux
0 to 40,000 hPa
1 lux
±20 lux ±5% of actual value,
whichever is higher
Noise Index
dB
Tier 1 through 5
-
-
Dust (PM1)
µg/m3
0 to 1,000 µg/m3
1 µg/m3
±15 µg/m3 (0 to 50µg/m)
± 10% (50 to 1,000µg/m)
Dust (PM2.5)
µg/m3
0 to 1,000 µg/m3
1 µg/m3
±15 µg/m3 (0 to 50µg/m)
± 10% (50 to 1,000µg/m)
Dust (PM4)
µg/m3
0 to 1,000 µg/m3
1 µg/m3
±15 µg/m3 (0 to 50µg/m)
± 10% (50 to 1,000µg/m)
Dust (PM10)
µg/m3
0 to 1,000 µg/m3
1 µg/m3
±15 µg/m3 (0 to 50µg/m)
± 10% (50 to 1,000µg/m)
TVOC
ppb
0 to 60,000ppb
1ppb
±15%
Carbon Monoxide (CO)
ppm
0 to 1,000ppm
0.1ppm
±1 ppm (0 to 20ppm)
±5% (20 to 1,000ppm)
Carbon Dioxide (CO₂)
ppm
0 to 1,000ppm
1ppm
±30 plus 3% of actual value*
Formaldehyde
ppb
0 to 2,000ppb
1ppb
±30 ppb (0 to 300ppb)
±10% (300 to 2,000ppb)
Nitrogen Dioxide (NO₂)
ppb
1 to 1,000ppb
1ppb
±20ppb (0 to 100ppb)
±20% (100 to 5,000ppb)
Ozone (O₃)
ppb
1 to 1,000ppb
1ppb
±10ppb (0 to 100ppb)
±10% (100 to 5,000ppb)
Ammonia
ppm
0 to 20ppm
0.1ppm
±0.5 ppm (0 to 5ppm)
±10% (5 to 20ppm)
Sulfur Dioxide
ppm
0 to 50ppm
0.1ppm
±1 ppm (0 to 10ppm)
±10% (10 to 50ppm)
Hydrogen Sulfide
ppm
0 to 100ppm
0.1ppm
±1 ppm (0 to 10ppm)
±5% (20 to 1,000ppm)

uHoo Aura base device measures the following:

Temperature, Relative Humidity, Air Pressure, Light, Sound, PM1, PM2.5, PM4, PM10, TVOC, Carbon Monoxide (CO), Carbon Dioxide (CO2), Formaldehyde (HCHO) and Virus Index™

Module A

In addition to the 13 sensors of the uHoo Aura base device, you can customize it to measure more parameters by choosing one of the options below:
  1. Nitrogen Dioxide (NO2) and Ozone (O3)
  2. Nitrogen Dioxide (NO2)
  3. Sulfur Dioxide (SO2)
  4. Hydrogen Sulfide (H2S)
  5. Ammonia (NH3)
  6. Carbon Monoxide (CO)

Module B

Temperature, Relative Humidity, Carbon Dioxide (CO2), TVOC, Air Pressure

Module C

PM1, PM2.5, PM4, PM10
